List of Dyson products

Dyson is a Singapore-based company and manufacturer of bagless vacuum cleaners (using cyclonic separation and brushless electric motors),

Technologies[

Dyson has developed various basic technologies for use in their products, including designing and manufacturing its own specialized motors.

Dyson Digital Motor

The electric motor marketed as the Dyson Digital Motor (DDM) is a direct current motor, operating on the switched reluctance principle. These brushless motors rotate at up to 110,000 rpm. The motor used a two-pole brushless rotor with a digital controller. Dyson said its efficiency was 84%, which was less than the 96% efficiency that is achieved in some brushless designs. In order to deal with the high speed and centrifugal forces, the impeller is made of carbon fibre reinforced polymer; the shaft is steel.

The first mass-produced version was named "X020" and used in the Airblade hand dryer; the later DDM "V2" was used for Dyson handheld vacuum cleaners.  Dyson has continued to develop its proprietary motor designs for various products, improving efficiency for increased battery life, and reducing acoustic noise, resulting in a "V8" version (for cordless vacuums) and a "V9" version (for a hair dryer), as of 2020.

Root Cyclone technology

The Dyson Root Cyclone technology is used in all Dyson vacuum cleaners from DC07 onward. The DC17, DC22, and DC23 use the improved "Root Cyclone & Core Separator", also called "Radix Cyclone", "Intermediary Cyclone", or "Level 3 Root Cyclone Technology".

Most of the current range use "2 Tier Radial cyclones", consisting of two cascaded levels of cyclonic separators to remove dirt and dust without requiring a bag or filter.

Vacuum cleaners

Model name

Most versions are identified by a name such as "DC14". Later upright and cylinder cleaners have labels such as "Small Ball" or "Big Ball" which relate to the machine's form factor. Cordless vacuum cleaners are identified by names such as "V11" or "V7" which denote the version of the appliance (the higher the model number, the greater its specification). Older cordless models pre-dating the Dyson V6 have names in the "DC14" style.

Some have submodels identified by a suffix indicating specific facilities, implemented sometimes by additional tools supplied. Suffixes with the same meaning vary from model to model.

• All Floors, Multi Floor, Wood+Wool: suitable for both hard surfaces and carpets.
• Allergy: suitable for filtering out microscopic allergens.
• Animal: designed to pick up animal hair better than a general-purpose model, and filter out fine particles. These machines come with a mini turbine tool to help remove pet hair, human hair and cotton fibres from upholstery, cars, and confined areas.
• Motorhead: cylinder or handheld model with direct-drive motorised brush head.
• Full Gear: same features as "Animal", with more attachments.
• Absolute: has a full range of tools and is typically the top-of-the-line model.

Special Edition models

Other suffixes may indicate exclusivity to certain stores, e.g. "Comet Exclusive" and "Overdrive" (Comet) or "Blitz it" (Currys).

Some are limited editions:

"Drawing" limited editions

These machines feature a different range of tools to the usual "Multifloor" and "Animal" versions and also appear in different colours. The Drawing later became exclusive to the British John Lewis Department Stores.

"De Stijl" limited editions

Some of the early Dyson models (DC01, DC02, DC04) were available in a "De Stijl"  colour scheme of purple, red and yellow, in homage to the Dutch design movement of the same name.

"Dyson Antarctic Solo" limited editions

In 1996, 100,000 recoloured DC01 and DC02 models were produced as part of a fund-raising effort for Ranulph Fiennes's solo expedition to the Antarctic. For these models, the yellow parts found on the mainstream models were replaced with light blue ones, and on the DC02 Antarctic Solo the body was also recoloured in white instead of silver.[4]

Current models

v15 and v12 came out in 2022

Upright

Model name


Launch year

Description

DC65/UP13/DC66

2014

The DC65 (DC66 in Canada)—is an update of the DC41. The vacuum features an updated root cyclone and a redesigned brush roll with more power than the DC41 and a better edge cleaning system. Some variants (like the Animal model) include the Tangle-Free Turbine Tool. Dyson has undergone a name change to their models, and this appears to be the same base design as the new UP13 model marketed as the "Dyson Ball Allergy". Boxes now contain new product code areas (which may make comparisons slightly easier) in the form [Model Type: UP = upright (previously codes were all DC)] [# ex: 13,19,20,40] [AC = ?] [Marketing description. OR = Origin, ALE = Allergy, AN = Animal, MF2 = Multi-Floor 2, ] [BMR = ?, SSE = ?, IRSY = ?, IRSPU = ?] [Country Code: US]

Small Ball

2015

The Dyson Small Ball replaces the DC50 small upright in 2015, after the introduction of the EU 2014 directive on mains powered vacuum cleaners. It is very similar to the DC50, but with refinements to the motor performance, and also a change to the handle wand, which it became a metal wand as on the DC24 to address issues with excessive flexing of the all plastic handle on the DC50.

Cinetic Big Ball (DC75/DC77/UP14)

2015

The DC75 (DC77/UP14 in North America) is Dyson's upright version of the Cinetic vacuum. Contains Cinetic technology with lifetime filters as well as Dyson's auto-adjusting motorized brushroll. The lifetime filters were guaranteed within the 5-year warranty period.

Ball (DC41MK2/DC5

2017

Updated / renamed version of the DC41MK2 and DC55. Also still known as the DC41 MK2 and also DC55 in certain retail outlets but simply as Dyson Ball from Dyson UK

Light Ball (UP2

2017

The Dyson Light Ball (UP22) is the replacement for the DC40 (ERP) upright, and is similar to the DC40 ERP in many respects except that it has a totally redesigned powerhead, incorporating a direct drive, large diameter brushroll with an internal "epicyclic" geared motor, similar to the DC50 and Small Ball. The powerhead has 3 levels of suction controlled by a slider switch which opens and closes various valves and gates on the powerhead. It is rated at 700W and 80db, in compliance with the EU regulations 2017 for mains powered vacuum cleaners. The Light Ball also has a longer reach cable than the DC40 and different tools with the "quick release" red button system.

Ball 2 (UP24 in UK and UP20 in the U

2017

Models designated "2" incorporate updates and improvements on the original model of their given locale. European models are compliant with the 2017 EU regulations for mains powered vacuum cleaners, and differ in design from non-EU models.

Canister

Model name


Launch year

Description

DC63

2014

DC63 is a line of small canister vacuums developed for Asian markets. It uses a Dyson Digital Motor V4 and has 2 Tier Radial Root Cyclones. It is sold in Japan with handle remote operation, a motorized brush bar and 'fluffy' hard floor tool.

Cinetic Big Ball (CY22)

2015

The Dyson Cinetic Big Ball canister vacuum features Dyson's new Cinetic technology with lifetime filters. The machine and filters are warrantied for 5 years of use.

Big Ball (CY23)

2015

The Dyson Big Ball (CY23) is an standard cyclonic model with washable filters. Almost identical in appearance to the Dyson Cinetic Big Ball cylinder model.

Cinetic Big Ball 2

2017

Models designated "2" incorporate updates and improvements on the original model. European models are compliant with the 2017 EU regulations for mains powered vacuum cleaners, and differ in design from non-EU models.

Big Ball 2

2017

Models designated "2" incorporate updates and improvements on the original model. European models are compliant with the 2017 EU regulations for mains powered vacuum cleaners, and differ in design from non-EU models.

Cordless

Model name


Launch year

Description

DC72

Image of a Dyson V6 with an attached-mini motorized head. All Dyson handheld/handsticks have similar, but not identical, main bodies.

2015

For specific markets (e.g. Canada, Singapore, Continental Europe); based on the V6; very similar to the DC59.

V6 (SV03/SV04/SV05/SV09)

2015

The Dyson V6 range is the replacement for the DC59 handstick and DC58 handheld cordless vacuum cleaners. Powered by the Dyson digital motor V6. This power-dense motor uses digital pulse technology and a neodymium magnet to spin at up to 110,000 rotations per minute. Its small size means that the machines it powers can also be small, light and powerful. The Dyson brand, as well as various reviews, claim that the V6 can have up to a 20-minute run time. The Dyson V6 comes in many different models with varying tools and accessories, including the Dyson Fluffy hard floor roller motorised head, and its top of the range model, the V6 Absolute comes with full HEPA filtration and a 50W main powerhead, giving 150% more brushbar power than the standard 20W powerhead found on lower models. Some versions of the V6, such as the Animal Extra and the Total Clean come with a 35W main powerhead with 75% more brushbar power than the standard head. The V6 develops 28 Airwatts of suction in its extended runtime mode, and 100 Airwatts of suction in its MAX mode, but runtime on a full charge in MAX mode is limited to 6 minutes. Runtime on a full charge using extended run time mode is 20 minutes with the non motorised tools attached, and 15 – 17 minutes with the motorised heads attached. The V6 has been an immensely successful machine for Dyson, but did have issues such as a short runtime, a small dust cup capacity and less than easy dust cup removal, which were all addressed with the next generation of cordless models, the V8 and V7 ranges, which are due to replace the V6.

V8 (SV10/SV25)

2016

The Dyson V8 is an upgraded version of the V6 with better battery life (up to 40 mins without the brush heads), a larger dust cup capacity, modifications to the debris emptying process (Called the "Hygienic dirt ejection system"), and reported quieter operation than its predecessor due to a different noise frequency and noise dampening post motor HEPA filter. The V8 produces 22 Air watts of suction on normal (extended runtime) power (28 on the V6) and 115 airwatts in MAX mode (100 on the V6). Their motorized floor heads are driven by their own separate motors, which are a 50W main motorised powerhead with nylon and carbon fibre filaments for carpet use and hard floor dusting, a 20W "Fluffy" soft roller head for hard floor cleaning, and a 20W mini motorised head, with nylon bristles. Runtimes of the V8 in extended run time mode are 40 minutes with non motorised tools attached, 30 minutes with the fluffy head or mini motorised head attached, and 25 minutes with the main 50W powerhead attached. In MAX mode, the run times are approximately 7 minutes regardless of what tools are fitted. The V8 has full HEPA filtration provided by a removable and washable HEPA exhaust filter located on the back of the motor housing. The HEPA filter system was carried over from the V6 Absolute. The V8 also has a washable pre-motor filter so theoretically no filter replacements should be necessary during the life of the machine. The battery on the V8 is replaceable if necessary.

V7 (SV11)

2017

Based on the design and overall look of the Dyson V8, the V7, which was launched in 2017, uses a similar digital motor and accessories. However, being a less expensive model to purchase, it has some differences to the higher priced V8. The battery can only run the V7 for up to 30 minutes on a full charge, whereas the V8 can run for up to 40 minutes. The V7 is equipped with a 35W main motorised powerhead, compared to one with 50W on the V8, and also some models of V7 come with a 20W mini electric turbo tool of a slightly differing design to that of the V8. As it has a physically smaller battery than the V8, the V7 weighs less than the V8. In terms of performance, the V7 produces 21 Airwatts of suction on "extended run time" mode, compared to 22 on the V8 and 28 on the V6, and it produces 100 Airwatts (as on the V6) on Max mode, compared to 115 airwatts on the V8. Most models of V7 do not come equipped with a HEPA removable exhaust filter. Like the V8, the V7 incorporates the hygienic dirt ejection system, and the quick release "red button" tools system, and it also has the same, larger dust cup capacity of the V8. It also, like the V8, runs for up to 7 minutes, when put in Max mode.

V8 Carbon Fiber

2017

The Dyson V8 Carbon Fiber is an upgrade version of V8 with a much more powerful motor. The V8 Carbon Fiber produces 155 AW (115 AW on the original V8) in MAX mode. The battery is rated at 40 minutes (same as original V8) in the normal mode.

V10 (SV12/SV13/SV27)

2018

The Dyson V10, launched in March 2018, is a successor to the V8. It implements a faster motor, larger bin capacity, "point and shoot" hygienic bin emptying system, and a single "all in one" washable filter consisting of both the pre-motor and post motor filter. It has 3 motor speeds, selectable via a pushbutton.

There are two distinct models of the V10 with different motors, filter assemblies and bin sizes. The V10 with larger bin produces 15.8 airwatts on low speed, the medium speed gives 33 airwatts, and the maximum speed gives 151 airwatts of suction. Run times are extended up to 60 minutes for ECO (low power) mode, and 5 minutes in MAX (high power) mode. A smaller version of the V10 with a V8-sized bin implements a different motor with lower power, as well as a smaller filter assembly.

Like the V8, it has a wall mounted charging dock and shares the same motorised floor head architecture. Prior to its release, Dyson announced that they were ceasing developing new corded vacuum models,  this was also mentioned on Dyson's official website.

V11 (SV14/SV15/SV17/SV28)

2019

The Dyson V11 was released on the 27 March 2019, sharing many of the components of the V11 with an upgraded motor and fan. The V11 lineup includes the V11 Animal, Torque Drive, and Absolute models. It uses current sensors to automatically adjust power to the floor type. The Torque Drive, Absolute, and Outsize models have LCD screens that show the remaining run time at the current power level.

V11 Outsize (SV16/SV29)

2020

Dyson launched an additional V11 model in November 2020, the Outsize, which has increased bin capacity and a larger frame. It includes a wider floor head and produces greater airflow and suction than previous models.

V12 Slim (SV20/SV30)

2020

Dyson revealed the new Digital Slim vacuum for Asian markets in August 2020, which is both smaller and lighter than the V11.

V15 Detect (SV22)

2021

The V15 Detect was announced on 24 March 2021. The main feature of the model is its laser detect technology, a small laser that can detect hidden dust particles as small as 10 microns on hard surfaces. It also includes a piezo detector which enables the user to see the amount and size of particles collected displayed on a LCD screen and the remaining battery life displayed in a real time countdown.

G5 Detect

2022

Dyson G5 Detect is equipped with a fifth-generation Hyperdymium motor, 135,000 revolutions per minute, with a strong suction output of up to 262AW, becoming Dyson's first-floor cleaning product that has been proven to capture and lock viruses.

Omni-glide

2021

Other

Model name


Launch year

Description

360 Eye

2014

The Dyson 360 Eye, a floor cleaning robot, uses a 360° panoramic vision sensor and IR distance sensors to map a room and navigate, enabling it to perform a systematic cleaning pattern that covers the accessible floor area only once. Based on the DC06, the 360 Eye was launched in 2014, Dyson's initial entry into this market segment also features cyclonic dust separation, a Dyson digital motor V2 for high power suction, tank treads for traction, a full-width brush-bar, and user interface via a free app.

360 Heurist

no image

2019

The 360 Heurist is the upgraded version of the 360 Eye. The Heurist, released in summer of 2019, has a better navigation system, and now includes an LED light ring so this camera-based bot can be used in dark rooms.

Discontinued models

Upright

Model name


Launch year

Description

G-Force

1983

"G-Force" was the name given to Dyson's first widely available vacuum cleaner. It was the first to use "Dual Cyclone" separation technology. Licensed to the Japanese company Apex Inc., and only available on the Japanese market, it was not sold under the Dyson name. Dyson used the money he earned from G-Force to start up the Dyson company.

DC51

A lightweight upright model  "with two tiers of smaller cyclones".

DC24

2008

A small version of the DC25. Also uses ball technology with separate brushroll motor. It weighs 5.4 kilogrammes (11.9 pounds) and has 115 airwatts of suction power. It is small and compact, and the handle compacts further for easy storage. It appeals to people who prefer a lightweight cleaner. Like the DC25, this model has proved to be a big seller, due to its extremely compact size, but did have quality issues with the brushroll motors, some of which have failed prematurely. Was superseded by the DC50 in November 2012

DC42

A version of the Dyson DC40 offered for sale in Canada.

DC43

A version of the Dyson DC41 offered for sale in Canada.

DC55

Currys (UK) Exclusive model. Same as the Dyson Ball and DC41 MK2 but with extra tools and a red colour on the cyclone bins. ***Still available as at Dec 2017 but shortly to be discontinued due to its non-compliance with the maximum allowable noise level set by the EU in Sep 2017.

DC33

2010

Revised version of the DC27/DC28. Replacement for the DC14, upright wheeled cleaner that does not use ball technology. Available as Multi Floor (Yellow), Stubborn (White), Animal (Purple), i (Red).

The DC33 has a plastic telescopic pole with smaller diameter than the metal telescopic pole of the DC14, so attachments from older Dyson's such as the DC14 do not fit the DC33. This model more closely resembles the old DC14 than the DC27 did, using exactly the same style of floorhead as the DC14, DC07 and DC04. The plastic wand pole has been criticised as a lowering of quality from the older metal type, and also causes the main spine of the cleaner to flex more, without the support of the metal wand. The fact that older model's tools were not interchangeable was also criticised, with many buyers trading up from the DC07 or DC14 to the DC33, and finding that their old tools would not fit. The DC33 uses a single motor for the suction and to drive the brushroll via a mechanical clutch as on the DC04, DC07 and DC14. This unit has been discontinued as of July 2013. No replacement model has been announced.

In mainland Europe, the DC33c is a cylinder machine known as the "Allergy Musclehead"

DC18

2006

The 6.6 kilograms (15 lb) Dyson DC18 Slim, launched in September 2006 and produced until summer 2008, is a slimmer and lighter-weight successor of the DC15 Ball upright. The DC18's Root Cyclone system has been trimmed down to better accommodate the machine's slimmer profile; the DC15 uses 8 cyclones, the DC18, 6.

The ball design has been simplified for the DC18: rather than riding on a large ball that encloses the primary motor, the DC18 rides on a thin, cigar-shaped roller that provides more space for separate motor enclosure and airway paths.

DC03

1997

The DC03, Dyson's second upright vacuum cleaner, released in 1997, was a lightweight (6.9 kg), low profile upright cleaner. It resembled a twin-cylinder version of the DC01, contained one normal cylinder and a second which contained a pair of HEPA filters. The DC03 had a smaller, more compact 700W motor, and while its suction power was lower than any of the currently available uprights at around 100 Airwatts, its heavy-duty filtration system allowed it to survive for many years after the rest of the original Cyclone cleaners were discontinued. It was the first upright model to feature brush control, via a clutch between the motor and the brushroll, and was able to be stored hung on a wall. It was also the first Dyson to have the Reversible Hose, like on the DC07 and DC24 Ball

DC04

1998

The DC04, released around 1998, had improved filters fitted as standard. The pre-motor filter was washable and was relocated to the top of the cyclone assembly, and the tools stored on the top of the filter housing. Most models also featured the new clutch controlled brushroll bar introduced on the DC03.

DC07

2001

The DC07, released in 2001 was the first implementation of Root Cyclone technology into a cleaner. In features it was similar to the DC04, but included a bottom drop bin, controlled by a trigger in the top of the cyclone housing, which made for easier emptying, and the handle wand was also able to be reversed and fitted to the hose cuff at the handle, so making it easier to use than that on the DC04. Many models were fitted with clutch controlled brushbars.

The DC07 had a new 1400W motor that provided 280 Airwatts, making it about the most powerful model that Dyson made, and also the noisiest in use, with much of the operating noise coming from the upwards mounted cyclone assembly. It weighed 9 kg. The DC07 had a long production run from 2001 until 2008, and came in many different colour combinations. During the DC07 production run, in 2002, Dyson switched all manufacturing of its vacuum cleaners from Malmesbury, UK to a new factory in Malaysia.

DC14

2004

The DC14 was released in 2004. It is a revision of the DC07 upright vacuum cleaner with lower centre of gravity and 'telescope reach'. It uses Dyson's Root 8 Cyclone technology, which maintains constant suction. Aside from the different design of the cyclone assembly and bin, the DC14 looks very similar to the DC07. It also has the same motor as fitted to the DC07 and the same floorhead (with the exception that the DC14 has a large debris channel fitted to the front of the brushroll housing). Due to the different downwards pointing cyclone design, the DC14 was slightly quieter in operation than the DC07 was, but still had the familiar motor noise as it used the same 1400 watt motor. Like the DC07, the DC14 comes in many variants, the standard DC14 (the Origin, non clutched), the All Floors (Clutched), the Allergy (Clutched), the Animal (Clutched, + mini turbine tool) and other special editions and colourways. As of January 2012 listed as "End of Line" on Dyson Web site.

DC15

2005

The DC15, known as The Ball was released in 2005 in three variants, the DC15 All Floors, Allergy and Animal, and is loosely based on the DC14. It was the first vacuum to use a ball instead of existing static wheels, so as to make it more possible to steer and maneuver the cleaner around obstacles and corners, in conjunction with a universal joint mechanism on the cleaner head, by twisting the handle to the right or left. The inspiration of the "Ball" system originated from the Ballbarrow, James Dyson's first invention.

The DC15 is a complex machine compared to earlier upright models, and is the first Dyson upright with an independent motorised brushroll, controlled by a switch next to the main power switch. The main suction motor is housed inside the "ball".

Due to its high launch price, its weight (8.6 kilograms (19 lb)), and the fact that it may have initially been seen as a gimmick, not that many DC15s were sold, with the cheaper DC14 remaining much more popular. The lightweight DC18 was launched late the following year, addressing the DC15's biggest criticism, its heavy weight.

DC25

2008

The DC25 was the replacement for the DC18, and was a scaled down, smaller version of the DC15 ball, and a larger version of the DC24. It was replaced by the DC41 in 2011. Like the DC15, it featured a suction motor located inside the ball, and separate brushroll motor which could be switched on and off independently of the suction motor, for using the vacuum cleaner on hard floors. It featured a post motor filter also inside the ball.

DC27

2009

The DC27 is an update on the DC14. The DC27 is a full size upright which has wheels rather than a ball, an auto-adjusting cleaner head and "root-cyclone" technology. It also features an extending wand and hose and has a large debris channel to pick up large dirt particles.

C50

2012

The DC50 was released at the end of 2012, and is an update on the DC24. It is a very small and lightweight upright ball cleaner incorporating the technologies introduced on the DC41 (i.e. self-adjusting brushroll), plus the addition of a new brushroll motor mounted inside the brushroll to save on space. The brushroll also incorporates carbon fibre bristles found in the DC35 and DC44 models. It weighs 5.4 kg (11.9 lbs) and has a suction rating of 140 airwatts, with a dirt capacity of 0.8 litres. Also featuring the 2 tier radial cyclone system found on the DC47. In Canada it is called the DC51. In 2015, the DC50 was renamed the "Small Ball" and underwent a few minor changes.

DC17

2006

The Dyson DC17 is an upright cleaner launched in October 2006 in the US. Although visually similar to the DC14, it contains new technologies. The first upgrade is the use of Dyson's Level 3 Root Cyclone.[20] This system incorporates 11 cyclones to more efficiently filter sand and dust particles out of the airstream. In this system, the airflow travels from the low speed outer cyclone to two intermediate cyclones that filter out the bulk of dust and sand particles that are drawn into the system. Beyond that, the airflow flows through the remaining eight high speed cyclones which filters any remaining dust particles out of the airstream. The Level 3 Root Cyclone improves upon the original Root Cyclone system with its capability to more efficiently separate sand particles from the air flow, a problem with the earlier system.

The second change with the DC17 upright is the brushroll design. While the brushrolls used on the DC07, DC14 and DC15 were designed with European carpets in mind, the DC17's brush roll was designed for North America with a cylindrical shape, a large diameter, and short stiff bristles. A separate motor drives the brushroll, unlike the DC07 and DC14, which use power from the main motor via clutches. This made the DC17 the most effective of Dyson cleaners on carpeting.

The third change is a new colour scheme for the DC17, and also the Dyson DC16 Root 6 Handheld; the bright colours and silver tones are toned down in favour of shiny metallic accents and titanium as the main colour for the entire machine.

The level 3 root cyclone system on the DC17 was quietly redesigned due to a gasket defect that allowed dirt to enter the cyclones backwards, clogging them and causing the cleaner to lose suction; almost all of the original DC17s had this problem. The redesigned cyclone pack, fitted to later DC17s, resolved this issue. Older DC17s were not recalled, but Dyson gave out and sold many of the redesigned cyclone packs.

DC40

2012

The Dyson DC40 upright vacuum released in early 2012. The DC40 vacuum is Dyson's counterpart to the previously released DC41 Animal. The DC40 has Multifloor and Animal editions that utilise the Dyson ball technology. In 2015, following the introduction of the 2014 EU regulations, the DC40 was slightly modified to its powerhead and motor, whereby the motor was re-rated 700W, and the powerhead gained much more aggressive agitation and had the carpet guard strips removed. The DC40 (ERP) was replaced in 2017 by the Dyson Light Ball.

DC41

2011

The Dyson DC41 upright released in late 2011 as the replacement for the DC25, is the first upright vacuum with Dyson's new Radial Root Cyclone technology as well as an automatic height adjuster which provides the maximum amount of power in the suction head. The cleaner also has Dyson's new high-powered turbo brush for the hose. The DC41 uses ball technology. In 2015, the DC41 was updated to become the DC41 MK2, in which it was made compliant with the new 2014 EU directives for mains powered vacuum cleaners, and its motor changed to a 700W rated motor, and its powerhead was revised to take into account its lower powered suction motor. The DC41 MK2 was later renamed simply the "Dyson Ball", but is still known as DC41 MK2 in certain retail stores.

DC01

1993

The first vacuum cleaner sold under the Dyson name was the DA001, launched in May 1993. It was a domestic upright model that used the patented "Dual Cyclone" technology and was made in Chippenham, England. After a short period, it was renamed the DC01 and production later moved to Malmesbury, at the company's new factory/research centre. The DC01 had a single motor which provided the suction and also drove the brushroll directly via a single rubber toothless belt with no form of "brush control" (where the user can turn off the brushroll for use on hard floors), so was mainly designed to use on carpeted floors. It stored its hose on the back of the housing as part of the handle wand, and removing the handle wand enabled this stretch hose to be used. This was the only Dyson upright not to use washable pre-motor filters; these had to be purchased and replaced every three months. It also had a choice of post motor filtration – standard or HEPA (High Efficiency Particle Arrest) according to the model purchased. It competed with models like the Hoover Turbopower, and was priced very high in comparison to other bagged cleaners. The suction power of the DC01 is 90 airwatts. Dyson no longer supports this model, nor produces parts for it.

DC28

2009

This was another upright model produced for the US market. It was the replacement for the DC17. Has a powered cam to adjust the height of the brushbar ("Dyson Airmuscle") controlled from a set of buttons by the main power switch above the cyclone assembly, a pneumatic actuator to keep the cleaning head on the floor, and a high-torque clutch to give extra power to the brushbar.

Cylinder

Model name


Launch year

Description

DC02

1995

The DC02, launched in 1995, was the first cylinder (canister) model sold by Dyson. Its shape allowed it to sit on stairs. Like the DC01, it used Dual Cyclone technology. It was not that popular during its production run and sold fewer than the DC01. The DC02 is no longer supported by Dyson.

The DC02 was available in several special editions:

• The De Stijl was colored purple, red and yellow, in homage to the Dutch art movement from which it takes its name. It was produced in a limited edition of 20,000 units.
• The DC02 Clear was produced in clear blue and green plastic, allowing the user to see its internal components through the casing.
• The Antarctica Solo model, coloured white and pale blue, helped raise funds for the Breakthrough cancer charity, whilst commemorating Sir Ranulph Fiennes' solo trek across Antarctica. Each of the limited edition run of 100,000 machines bore the image of Ranulph Fiennes' autograph.
• The Recyclone was the first vacuum cleaner to be made of recycled plastic. Originally intended as a test-run for a range-wide 'Recyclone' scheme, the concept never went beyond a very small production run of DC02s. They were coloured green with organic pigment.

DC05

1998

The DC05, launched in 1998, was the second cylinder model. It was designed as a replacement for the DC02. The 'Motorhead' version was the first Dyson to offer a "powernozzle", a floor nozzle with a motorized brushroll bar for improved performance on carpets.

DC08

2002

The DC08 was a new cylinder revision, released in 2002, incorporating the Dyson Root Cyclone technology found on the DC07. The DC08 was the replacement for the DC05. It was the first of the Dyson cylinder models to feature the new "Animal" derivative first seen on the DC07, which essentially meant that the cleaner was capable of dealing effectively with pet hair and dander. Animal models came with an air driven turbine floorhead and mini turbo brush for effective pet hair removal from carpets and furnishings – they also came equipped with Hepa post-motor filters.

None of the DC08 models had electric motorised floorheads. Like the DC07, the DC08 was fitted with an uprated motor giving it more suction power, handled by the new root 12 cyclone system the DC08 was equipped with. This higher power output could drive the main turbo floorhead without the need for an electric motor and the expensive wiring that the DC05 motorhead had.

Lower models in the DC08 range did not come with the turbine floorhead, having only the standard floorheads which were better-suited to hard flooring than carpets. Unlike the DC02, the DC08 did not have storage for its small tools in the body of the cleaner. As with the DC05, tools were stored on a small caddy attached to the suction hose. The DC08 had a long production run; it was upgraded to the DC08 Telescope wrap after the launch of the DC11, to enable it to be stored more efficiently, and was eventually superseded by the DC19. Early in the production run of the DC08, in 2002, Dyson switched production of all its vacuum cleaners from Malmesbury, UK to a new production facility in Malaysia.

DC08T

2003

Next product after the DC11 with 'Telescope Wrap'. Wand handle is telescopic and the hose wraps around the machine. Launched in 2003

DC11

2003

The DC11 was the first Dyson cylinder cleaner with Telescope wrap. Launched around 2003.

It had two separate dust bins and cyclone assemblies to make the machine smaller when it was packed away. It was only available in two variants, one coloured yellow and the other was a turquoise/aqua model. The DC11 was quickly superseded by the DC08T Telescope wrap, and not produced for very long.

DC12

2003

Small cylinder machine released in Japan. Launched near around 2003.

DC12plus

2005

Small cylinders in Japan. Top-of-the-range models are fitted with the Dyson Digital Motor, which rotates at 100,000 rpm.

DC19

2007

Cylinder model, without the Telescopic Wrap system.

It was the replacement of the DC08, and to all intents and purposes is virtually the same in appearance and design as the DC08.

DC19T2 Origin

2009

Same as DC19, but improved so that the brushbar can pick up on carpets and on hard floors. This model also used a plastic telescopic rod instead of the metal one found on the original DC19.

Still a current model as of November 2012.

DC20

2007

'Stowaway', as DC19 but with telescope wrap. Dyson have updated the DC08T (part of the DC08) series to form the DC20. Called the Dyson Stowaway in the UK. The colour scheme is new, and the cleaner is available in Standard, Allergy and Animal.

DC21

2008

Entering into the American Market in 2008, this model is known as the Stowaway in the United States, but as the Motorhead in the United Kingdom and other countries. It is the second cylinder vacuum from Dyson to have a motorised brushbar on the head of the nozzle. It is an advance on the DC08 Telescopic Wrap system, discontinued in some countries including the United Kingdom.

DC22

2008

Known as "Dyson Baby" or "Dyson Compact" or "Dyson Allergy" and two-thirds the size of the DC23. Using the Dyson Digital Motor and Core Separation which adds a third cyclone 'layer' to filter out smaller particles. Has turbine head and motor head versions.

DC23

2009

DC23 is similar in design to the DC21 but uses the new Core Separation that is also in the DC22. There is also a turbinehead animal version in Canada.

DC23 T2

A DC23 with different accessories and tools.

DC26

2010

Ultra compact cylinder model, the DC26, known as the Dyson "City" is the World's smallest vacuum with constant suction. Even smaller than the DC22. The machine is so small that it will fit onto a piece of A4 paper. With a very small dust container of 0.68 litres, and cord length of 5 metres, it was designed for small flats with primarily hard floors. It weighs just 5.6 kg and has an impressive 160 AirWatts suction power.

DC29

In Australia the DC29 is a cylinder model, an improved version of DC19. Very similar to DC19T2, the main differences being colour and tooling and non-HEPA machine. A HEPA filter is now included in 2012 'Multi-Floor' white models. In Canada, the DC29 is actually an upright model similar to the DC25. This appears to be the first instance of a particular model number being used on an Upright OR a Cylinder depending on country of destination

Supplied to Continental Europe and Australia (Cylinder type) and Canada (Upright type) (Not available in the UK). According to this Dyson review listing on the Australian website, the Dyson DC29 Multi floor is no longer available.

DC32

2009

Basically the same as DC23T2 (in the UK) with a revised color scheme and additional tooling.

DC36

DC38 version for Japan, France, South Korea and Canada.

DC37

unknown

DC39 version for Continental Europe and Canada.

DC38

Smaller version of the DC39.

DC39

2011

Dyson's new cylinder vacuum cleaner released in late 2011. It uses Dyson's Radial Root Cyclone Technology. Uses a ball and a swivel mechanism for improved manoeuvrability.

DC46

Version of the DC47 cylinder model for the Canadian, and the Japanese market.

DC47

2012

The DC47 was released at the end of 2012, and is an update on the DC38. It is a compact cylinder model based on the technologies featured on the DC38, but introducing the new 2 Tier Radial Root Cyclone Technology for greater suction and filtration, and also the new 2 channel floor tool.

It weighs 6 kg and has a suction power of 180 Airwatts.

DC48

2012

Version of the DC49 cylinder model for the Canadian, and the Japanese market. Launched in 2012.

DC49

Updated DC47, with more compact design and using the new digital motor v4. Billed by Dyson as its "smallest and quietest vacuum cleaner".

DC52

Version of the DC54 cylinder model for Continental Europe and Singapore

DC53

Exclusive model for Currys UK, the DC53 comes as the Total Clean version only, and is a DC39 in red and grey, with additional tools.

DC54

2014

Newest ball vacuum cleaner from Dyson. It uses Cinetic technology which Dyson says will not lose suction over 10 years. It is the first Dyson that does not require cleaning of filters. Consists of 54 cyclones with high frequency oscillating tips that vibrate to prevent clogging. Comes in Animal and Multi-Floor versions where it bundles a range of cleaning tools to tackle all surface types.

DC78

2014

A Canada-exclusive revision of the DC54 Cinetic Ball, offered in a single "Turbinehead" configuration.

Cordless

Model name


Launch year

Description

DC16

2006

The DC16, launched in 2006, is Dyson's first handheld vacuum cleaner based on the same technology as used in the DC14 and DC15 root cyclone upright vacuum cleaners. The DC16 has 36 airwatts of constant suction. The DC16 shares the same styling as the other recent upright and cylinder vacuum cleaners in the Dyson range, and weighs 1.5 kg (3.3 lb).

Also available in an Issey Miyake limited edition in which the manifold on the cyclone assembly is pink instead of the standard yellow, and an Animal version with a motorised brushbar for picking up pet hair and gold cyclone manifold. Newest to the range is the DC16 Car and Boat which is designed for car and boat cleaning, supplied with a car 12 V charger and has a blue cyclone manifold. The DC16 was replaced by the DC30 and DC31 which incorporated the Dyson Digital Motor, in replacement of the traditional motors found in the DC16.

DC30

Powerful handheld with a brushless switched reluctance motor.[30] Can provide 6 minutes of high and constant suction. It is smaller, lighter and more powerful than the DC16, which uses a conventional motor. The DC30 has a yellow cyclone manifold.

DC31

2009

The most powerful handheld, with the same motor technology as the DC30, but with a larger battery and dual power for more runtime. 10 minutes of high constant suction (at the same level as the DC30) or 6 minutes with 70% higher suction. Available as DC31 with a blue (UK and AUS), yellow (US), or red (EU) cyclone manifold, or the DC31 Animal which has a purple cyclone manifold.

DC34

2009

Another Handheld model similar to the DC31; launched in 2009.

DC35

2009

Dyson Digital Slim. Similar design to the DC30/31/34 but with detachable extension tube, modified electronics and motorised brush head. Launched in 2009. It was replaced by the DC44 and DC59.

DC44

2012

The Dyson Digital Slim DC44 is a cordless handstick vacuum cleaner which uses the same motorised brush head as the DC35 as well as the Radial Root Cyclone Technology. Has an extension pole to make it similar to a cylinder cleaner's handle, pole and floorhead. Improves on the DC35 by incorporating a more powerful brush bar motor and having more cleaning tools. It was replaced by the Dyson DC59 / V6.

DC45

Dyson Digital Slim for Canada and Continental Europe, essentially the same as the DC44

DC56

2013

Known as the Dyson Hard, cordless handstick similar to the DC44, for hard floors, powered by Dyson digital motor V2, has 5 cyclones. Weighs 2.92 pounds (1.32 kg), including a 22.2V rechargeable lithium ion battery.

DC57

Handheld, same as DC56 for Canadian and Singapore markets.

DC58

Handheld, powered by Dyson digital motor V6, has 15 cyclones.

DC59

Image of a Dyson V6, a relabelled DC59.

2014

The DC59 replaces the DC44 and is claimed to remove as much dust as a corded vacuum. This is made possible by the combination of the Dyson digital motor V6, 2 Tier Radial cyclones and the latest floor tool with carbon fibre filaments. This power-dense motor uses digital pulse technology and a neodymium magnet to spin at up to 110,000 times a minute. Its small size means that the machines it powers can also be small, light and powerful. The DC59 (and DC58) were replaced by a very similar cordless handstick simply named the Dyson V6.

DC61

For specific markets (e.g. Singapore); based on the V6; Handheld Version; very similar to the DC59.

DC62

For specific markets (e.g. Canada, Singapore, Continental Europe); based on the V6; very similar to the DC59.

Other

Model name


Launch year

Description

DC06

2000 (never sold)

Dyson's first robotic vacuum cleaner, equipped with the Dyson Digital Motor, had not proceeded beyond the home-trial stage. By 2012, as cost and weight needed reducing. It had the ability to 'learn' the room, and to distinguish between solid objects, such as walls and furniture, and human beings, pets, etc. by utilizing sensors and specially-written navigation software. Dyson DC06 first appeared on Dyson's UK website in 2000.
